Discover our attractive Corten A sheets, built to withstand harsh environments and significant weather conditions. Ideal for architectural and industrial applications, these sheets offer a blend of durability and aesthetics.” which are great for. Available in various sizes and customizable materials, they are versatile solutions-giving for various services.
Standard : ASTM A588, A242, EN 10027-1, CR 10260 & IRSM
Material : Corten A ,Corten B , S355J0WP ,S355J0W,S355J2W , A588 Grade A, A588 Grade B, A588 Grade C , A242 Type 1 , A 588 Gr. K , A 242 Type-2 , IRSM-41, SA588 Grade A, SA588 Grade B, SA588 Grade C
Thickness : 0.3-500mm
Width : 1000-3500 mm
Length : 1000 – 12000 mm
Production : Hot-Rolled (HR) / Cold-Rolled (CR)
Surface : Black painted,PE coated,Galvanized,color coated,anti rust varnished,anti rust oiled,checkered,etc
| Corten – A | ASTM 588 Grade A | ASTM 242 TYPE -1 | IRSM 41 -97 | |
|---|---|---|---|---|
| Carbon, Max | 0.12 | 0.19 | 0.15 | 0.10 |
| Manganese | 0.20-50 | 0.80-1.25 | 1.00 | 0.25-0.45 |
| Phosphorus | 0.07-0.15 | 0.04 | 0.15 | 0.07-0.11 |
| Sulphur, max | 0.030 | 0.05 | 0.05 | 0.030 |
| Silicon | 0.25-0.75 | 0.30-0.65 | 0.25-0.40 | 0.28-0.72 |
| Nickel, max | 0.65 | 0.40 | – | 0.20-0.49 |
| Chromium | 0.50-1.25 | 0.40-065 | – | 0.30-0.50 |
| Molybdenum, max | – | – | – | – |
| Copper | 0.25-0.55 | 0.25-0.40 | 0.20 min | 0.30-0.39 |
| Vanadium | – | 0.02-0.10 | – | 0.050 |
| Aluminimum | – | … | – | 0.030 |
| Tensile Strength | Min. Yield Point | Elongation | |
|---|---|---|---|
| CORTEN A | [470 – 630 MPa] | [355 MPa] | 20 % min |
| ASTM 588 GR. A | [485 MPa] | [345 MPa] | 21% min |
| ASTM 242 TYPE -1 | [480 MPa] | [345 MPa] | 16% min |
| IRSM 41- 97 | [480 MPa] | [340 MPa] | 21% min |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Corten A Sheet as per DIN, ISO, JIS or ANSI Standard.
Corten A Sheet applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Corten A sheets are designed to develop a protective rust-like appearance when exposed to weather, which serves as a natural corrosion barrier. This unique patina formation eliminates the need for additional corrosion protection coatings in most applications, reducing maintenance requirements and costs. However, in specific environments or for prolonged exposure to harsh conditions, supplementary coatings may be considered to further enhance longevity and performance, depending on the project’s requirements and aesthetic preferences.
