Explore our Corten B sheets’ strength and corrosion resistance, designed to last in architectural and industrial conditions. These sheets are known for weathering, ensuring durability and minimal durability. They have” a variety of sizes, customizable finishes, “And Corten B sheet offers a versatile solution for various construction projects. Our premium Corten B sheet can elevate your system with durability and exceptional aesthetics.
Standard : ASTM A588, A242, EN 10027-1, CR 10260 & IRSM
Material : Corten A , Corten B , S355J0WP ,S355J0W,S355J2W , A588 Grade A, A588 Grade B, A588 Grade C , A242 Type 1 , A 588 Gr. K , A 242 Type-2 , IRSM-41, SA588 Grade A, SA588 Grade B, SA588 Grade C
Thickness : 0.3-500mm
Width : 1000-3500 mm
Length : 1000 – 12000 mm
Production : Hot-Rolled (HR) / Cold-Rolled (CR)
Surface : Black painted,PE coated,Galvanized,color coated,anti rust varnished,anti rust oiled,checkered,etc
| Grade | C | Si | Mn | P | S | Al | V | Cu | Cr | Ni |
|---|---|---|---|---|---|---|---|---|---|---|
| CORTEN B | 0.19 max | 0.30 – 0.65 | 0.80 – 1.25 | 0.035 max | 0.030 max | 0.020 – 0.06 | 0.02 – 0.10 | 0.25 – 0.40 | 0.40 – 0.65 | 0.40 max |
| Grade | Yield strength ReL (N/mm 2) Min. | Tensile Strength Rm (N/mm 2) Min. | Elongation A50% Min. |
|---|---|---|---|
| COR-TEN B | 345 | 485 | 19 |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Corten B Sheet as per DIN, ISO, JIS or ANSI Standard.
Corten B Sheet applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Corten B sheets are designed to develop a stable rust-like appearance over time, which acts as a protective layer against further corrosion in most atmospheric conditions. This natural patina formation eliminates the need for additional corrosion protection coatings, making Corten B sheets low maintenance and cost-effective over their lifecycle. However, in specific environments such as marine or highly corrosive industrial settings, supplementary coatings may be considered to enhance longevity and performance based on project requirements.
