Hastelloy C22 wire stands as the pinnacle of corrosion-resistant wiring solutions, famous for its excellent performance in rigorous environments such as chemical processing plants, aerospace ventures, and marine engineering endeavors. custom-built primarily from a blend of nickel, chromium, and molybdenum, Hastelloy C22 wire showcases remarkable resistance to an array of corrosive agents, including potent acids, halides, and oxidizing compounds. Its robust composition guarantees enduring resilience, bolstering critical infrastructures against deterioration and ensuring seamless operation even in the most adverse conditions. Serving as a linchpin in industries grappling with corrosion challenges, Hastelloy C22 wire epitomizes ingenuity, providing steadfast dependability and extended service longevity amid aggressive substances and demanding operational requirements.
Specifications | : | ASTM B574 ASME SB574 |
Dimensions | : | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
Length | : | 100 mm TO 6000 mm |
Diameter | : | 10 mm To 100 mm |
Specialize | : | Filler Wire, Coil Wire |
Hastelloy C22 | |
Ni | Bal |
C | 0.010 max |
Cr | 20 – 22.5 |
Co | 2.5 max |
Fe | 2 – 6 |
Mn | 0.50 max |
Mo | 12.5 – 14.5 |
P | 0.02 max |
Si | 0.08 max |
S | 0.02 max |
W | 2.5 – 3.5 |
V | 0.35 max |
Density | 8.69 g/cm3 |
Melting Point | 1399 °C (2550 °F) |
Tensile Strength | Psi – 1,00,000 , MPa – 690 |
Yield Strength (0.2%Offset) | Psi – 45000 , MPa – 310 |
Elongation | 45 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Hastelloy C22 Wire as per DIN, ISO, JIS or ANSI Standard.
Water resistance: Hastelloy C22 is known for its exceptional resistance to various corrosion environments, including oxidizing and reducing conditions, which makes it suitable for use in complex medical applications where corrosion is a major concern.
Versatility: This alloy exhibits versatility in its application due to its resistance to oxidizing and reducing acids, as well as its resistance to chloride-induced pitting, cracking and corrosion
High-Temperature Performance: Hastelloy C22 maintains high-temperature mechanical properties, making it suitable for applications where exposure to high temperatures is a consideration
Chemical Compatibility: It is compatible with a wide range of chemicals, including sulfuric acid, hydrochloric acid, phosphoric acid and acetic acid, among others, making it suitable for use in a variety of pharmaceutical industries
Manufacturability: Hastelloy C22 wire is easily manufactured in a variety of forms, including wire, paper, plate and tubing, allowing for versatility in manufacturing processes
Longevity and reliability: Resistance to corrosion and high temperatures contributes to durability and reliability in service and reduces maintenance and downtime costs
Hastelloy C22 Wire applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Chemical applications: Hastelloy C22 wire is widely used in chemical industries where resistance to a wide range of aggressive chemicals is required and used in reactors, molds, piping systems and other equipment that handles acids, chloride, solvents, and other perishables.
Petrochemical Industry: Similar to the chemical industry, the petrochemical industry uses Hastelloy C22 wire in equipment such as heat exchangers, columns, and piping systems, especially where sulfuric acid, hydrochloric acid, and other substances a the prevalence of corruption
Pollution Prevention: Used in pollution control devices such as scrubbers and exhaust systems where acid gas and other corrosive pollutants are present
Chemical Industry: In the chemical industry, Hastelloy C22 wire is used in reactors, storage tanks, and other equipment where corrosion resistance is required, especially in processes involving acids, bases and solvents
Pulp and Paper Industry: Because of its resistance to chloride and other chemicals used in bleaching processes, Hastelloy C22 wire is used in pulp digesters, bleaching plants and other pulp and paper industry equipment.
Aerospace: For aerospace applications, Hastelloy C22 wire can be used in applications with high temperatures and hot climates, such as gas turbine engines
Corrosion resistance: Hastelloy C22 wire is known for its exceptional resistance to aggressive chemicals, including oxidizing and reducing environmental factors. Check the corrosion resistance of your application and make sure Hastelloy C22 corresponds to it.
Heat Resistance: Specifies the temperature of your application. Hastelloy C22 provides excellent resistance to high temperatures, making it suitable for high-temperature environments.
Mechanical properties: Consider the properties important to your application, such as absorption, gain, and resistance. Ensure that the selected Hastelloy C22 wire meets these requirements to withstand mechanical stresses.
Size and Diameter: Based on your application’s specific requirements, select the appropriate size and diameter of Hastelloy C22 wire. Consider factors such as conductivity, current carrying capacity, and dimensional tolerances.
Materials Requirements: Identify the processes and techniques used to manufacture materials within the scope of your project, such as welding, forming, or machining. Choose Hastelloy C22 wire compatible with these fabrication methods to ensure easy construction and assembly.
Compliance: Ensure Hastelloy C22 wire complies with applicable industry standards and regulatory requirements for your application. Consider certifications and specifications such as ASTM, ASME, and NACE.
Maintain Hastelloy C22 wire by regularly inspecting for corrosion or damage, cleaning with mild detergents and soft brushes, avoiding abrasive cleaners, and ensuring proper storage to prevent contamination. Follow manufacturer recommendations for welding, machining, and handling to preserve its corrosion resistance and mechanical properties.
Yes, Hastelloy C22 wire is recyclable. It can be reclaimed through various metal recycling processes, including melting and refining, to produce new Hastelloy C22 products or other nickel-based alloys. Recycling helps conserve resources and reduce environmental impact by reusing valuable materials in manufacturing.
Hastelloy C22 wire is not typically used for structural applications due to its primary strength lying in corrosion resistance rather than structural integrity. However, it can be utilized in components within structures where corrosion resistance is paramount, but load-bearing capacities are not the primary concern.
Hastelloy C22 wire is resistant to galvanic corrosion when coupled with other metals due to its composition primarily consisting of nickel, chromium, and molybdenum. However, in certain aggressive environments or specific conditions, galvanic corrosion may occur if coupled with dissimilar metals, requiring careful consideration during application.
