Explore our High Tensile Steel Fasteners selection, designed to fulfil diverse industry requirements with robustness and flexibility. Our fasteners adhere to rigorous standards, guaranteeing exceptional performance even in demanding environments. We emphasize personalized solutions, competitive pricing, and punctual delivery to ensure customer contentment. Rely on our reliable products to optimize your business activities, which are supported by our unwavering dedication to excellence.
| High Tensile Fasteners Grades | DIN 933 Grade 8.8, 12.9 and 10.9, |
| Size | Dia: M 20 – 100 mm 3/4“– 3.1/2” Inch |
| Standard | DIN EN ISO 4014, IS 1363/ IS 1364 & 4017 DIN 933/931 |
| finish | Plain / Hot dip galvanised/ Zinc plated |
| High Tensile Heavy Hex Bolt Diameter | F | H | D | C | |||||
| Width Across Flats | Height | Body Diameter | Width Across Corners | ||||||
| Max | Basic | Min | Max | Basic | Min | Max | Min | Max | |
| 5/8 | 1.062 | 1-1/16 | 1.031 | 0.444 | 27/64 | 0.378 | 0.642 | 1.175 | 1.227 |
| 3/4 | 1.250 | 1-1/4 | 1.212 | 0.524 | 1/2 | 0.455 | 0.768 | 1.383 | 1.443 |
| 1/2 | 0.875 | 7/8 | 0.850 | 0.364 | 11/32 | 0.302 | 0.515 | 0.969 | 1.010 |
| 7/8 | 1.438 | 1-7/16 | 1.394 | 0.604 | 37/64 | 0.531 | 0.895 | 1.589 | 1.660 |
| 1-1/8 | 1.812 | 1-13/16 | 1.756 | 0.780 | 3/4 | 0.658 | 1.149 | 2.002 | 2.093 |
| 1 | 1.625 | 1-5/8 | 1.575 | 0.700 | 43/64 | 0.591 | 1.022 | 1.796 | 1.876 |
| 1-1/4 | 2.00 | 2 | 1.938 | 0.876 | 27/32 | 0.749 | 1.277 | 2.209 | 2.309 |
| 1-1/2 | 2.375 | 2-3/8 | 2.300 | 1.036 | 1 | 0.902 | 1.531 | 2.622 | 2.742 |
| 1-3/8 | 2.188 | 2-3/16 | 2.119 | 0.940 | 29/32 | 0.810 | 1.404 | 2.416 | 2.526 |
| 1-3/4 | 2.750 | 2-3/4 | 2.662 | 1.196 | 1-5/32 | 1.054 | 1.785 | 3.035 | 3.175 |
| 2-1/4 | 3.500 | 3-1/2 | 3.388 | 1.548 | 1-1/2 | 1.327 | 2.305 | 3.862 | 4.041 |
| 2 | 3.125 | 3-1/8 | 3.025 | 1.388 | 1-11/32 | 1.175 | 2.039 | 3.449 | 3.608 |
| 2-1/2 | 3.875 | 3-7/8 | 3.750 | 1.708 | 1-21/32 | 1.479 | 2.559 | 4.275 | 4.474 |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These High Tensile Steel Fasteners as per DIN, ISO, JIS or ANSI Standard.
High Tensile Steel Fasteners applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
When selecting high-tensile steel fasteners, consider the application’s demands for strength and durability. Look for fasteners with appropriate tensile strength ratings to withstand the intended load and environmental conditions. Additionally, factor in corrosion resistance, thread type, and compatibility with other materials for optimal performance and longevity.
