Home > Stainless Steel >Stainless Steel 304H Forged Fittings
| Standard | ASTM A182 / ASME SA182 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 10.5 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer Stainless Steel 304H Forged Fittings as per DIN, ISO, JIS or ANSI Standard.
Due to their exceptional properties, Stainless Steel 304H Forged Fittings are essential components across many industrial sectors. Renowned for their corrosion resistance, they find widespread application in marine environments, enduring the rigours of saltwater exposure with longevity and reliability. In the construction industry, stainless steel fasteners play a pivotal role in structural assemblies, providing secure connections while maintaining structural integrity in outdoor and exposed settings.
Chemical applications: Stainless steel 304H forged fittings are commonly used in chemical plants where resistance to acids, alkalis, and other chemicals is required and in pipelines and reactors where resistance is required does not destroy.
Oil and Gas Industry: Stainless steel 304H fittings are used in the oil and gas industry to supply pipelines, wellheads, and other components critical to severe environmental conditions and products in high-pressure environment
Power generation: These products have applications in power plants, including steam, water, and other fluids pipeline systems. Their ability to withstand high temperatures and pressures make them suitable for boilers, heat exchangers and other generating equipment.
Corrosion resistance: Stainless steel 304H is known for its excellent corrosion resistance, especially in acid and chloride environments. Ensure mesh fittings are made of high-quality 304H stainless steel to assure optimal corrosion resistance.
Temperature and Pressure Analysis: Determine your application’s operating temperature and pressure conditions. Stainless steel 304H forged fittings are suitable for high temperature and high-pressure conditions, but it is important to match the fittings’ pressure and temperature levels with your application requirements.
Size and Design: Choose the correct size and thickness of the mesh fittings to ensure compatibility with your piping system. Consider pipe size, thread type (NPT, BSP, etc.), and installation (elbows, tees, couplings, etc.).
End connections: Specify the type of end connections required for your application, such as threaded, socket welded, or butt welded. Ensure that mesh fittings have correct end connections to facilitate installation and bonding with other piping system components.
