| Specification : | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
| Dimensions : | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| Size : | 1/2″NB TO 12″NB IN |
| Thickness : | Sch Sch 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160 Sch XXS |
| Types : | Seamless / ERW / Welded / Fabricated |
| Grades : | Hastelloy C22 (UNS No. N06022), Hastelloy B2 (UNS No. N10665), Hastelloy C-4 (UNS No. N06455) |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45% |
| Grade | C | Mn | Si | Co | P> | Fe | Mo | Ni | Cr | S | W | V |
| Alloy C22 | 0.010 max | 0.50 max | 0.08 max | 2.5 max | 0.02 max | 2 – 6 | 12.5 – 14.5 | Bal | 20 – 22.5 | 0.02 max | 2.5 – 3.5 | 0.35 max. |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Hastelloy C22 Pipe Fittings as per DIN, ISO, JIS or ANSI Standard.
Superior corrosion resistance: Hastelloy C22 exhibits exceptional strength in various corrosion environments, including oxidizing and reducing conditions, making it ideal for applications involving acids, chlorides, sulfides, and other aggressive conditions.
High-Temperature Performance: Hastelloy C22 maintains high-temperature mechanical properties with excellent thermal stability, ensuring reliable performance under demanding operating conditions.
Versatility: These fillers are highly versatile and can be used in a variety of industries in industries such as chemical processing, pharmaceuticals, oil and gas, pulp and paper
Exceptional strength: Hastelloy C22 provides incredible mechanical strength, enabling durable products to withstand high pressures and environmental stresses.
Ease of manufacture and weldability: Hastelloy C22 pipe fittings can be easily fabricated and welded using traditional methods, making them easy to install and maintain.
Cracking and pitting corrosion resistance: Hastelloy C22 exhibits resistance to localized corrosion, such as cracking and pitting corrosion, increasing the longevity and reliability of fittings.
Hastelloy C22 Pipe Fittings applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Chemical applications: Hastelloy C22 fittings are widely used in the chemical industry to handle volatile chemicals, acids and solvents. They are Ideal for reactors, distillation columns, heat exchangers, piping systems and other applications where anti-aggressive media is needed
Oil and Gas: Hastelloy C22 pipe fittings are used in midstream and downstream applications in the oil and gas industry. They are employed in offshore platforms, finishing facilities, pipelines, stainless steel pipelines, valves, fittings, and petrochemical plants.
Chemical and Biotechnology: The pharmaceutical biotechnology industry prefers Hastelloy C22 fittings due to their resistance to a wide range of chemicals and exceptional cleaning agents. They are used in reactors, fermenters, filtration systems, and other equipment where cleanliness and corrosion resistance are of paramount importance.
Aerospace and Safety: Aerospace and security applications require materials that can withstand harsh environmental conditions and chemicals. Hastelloy C22 fittings are used in aircraft fuel systems, missile components and marine applications where corrosion resistance, high temperature and stress corrosion cracking are required.
Pulp and Paper: In the pulp and paper industry, Hastelloy C22 pipe fittings are used in chemical recovery plants, bleaching plants, and digesters where chemical burns and high temperatures often cause chloride, sulfur resistance compounds, and other highly corrosive agents -are present in the processes.
Power generation: Hastelloy C22 fittings are used in electrical installations, including fossil fuel power plants, nuclear reactors and renewable energy installations
Compatibility: Hastelloy C22 is highly corrosion resistant, making it suitable for harsh environments such as chemical processing and industrial applications. Ensure that the fittings you choose are made of Hastelloy C22 for compatibility with your piping system.
Pressure and Temperature Ratings: Determine the maximum pressure and temperature to which the fitting will be subjected during your application. Select fittings with the correct pressure and temperature to withstand operating conditions without failure.
Size and Dimensions: Consider the size and dimensions of the pipe fittings to ensure they match the piping system to be installed. Check that the cables have the correct nominal pipe size (NPS) and thickness to ensure they are valid pipes in the system. Easy to join and flow.
End connections: Hastelloy C22 pipe fittings are available with end connection types such as threaded, socket welded, butt welded, and flanged ends. Select fittings with end connections that match the existing piping system and installation requirements.
Water resistance: Hastelloy C22 provides excellent strength in various corrosion environments, including oxidizing and reducing conditions. Ensure fittings have the necessary corrosion resistance to withstand your application’s specific chemicals or moisture in the mouth.
