Hastelloy C276 Coils are continuous lengths of flat metal strips made from the Hastelloy C276 alloy, a nickel-molybdenum-chromium superalloy known for its exceptional corrosion resistance in aggressive environments. These coils are typically used in applications requiring high strength, durability, and resistance to a wide range of corrosive substances, including acids, chlorides, and seawater. Common applications include chemical processing, petrochemical, and waste treatment industries, where Hastelloy C276 coils are formed and fabricated into various components such as heat exchangers, reactors, and piping systems.
| Standard | ASTM B575 / ASME SB575 |
|---|---|
| Thickness | 0.2mm – 5.0mm |
| Width | 3.2mm – 1500mm |
| Length | AS PER CUSTOMER’S REQUIREMENT |
| Test Certificate | Yes |
| Coils Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Form | Coil / Strip |
| Make | Jindal, Bahru, Posco Korea, Posco Thainox, Columbus, Acerinox, Aperam, Tisco, Nisshin, Nippon And Many More Mills. |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Hastelloy C276 Coils as per DIN, ISO, JIS or ANSI Standard.
Hastelloy C276 Coils applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Corrosion Resistance: Evaluate the specific corrosive environment the coils will be exposed to and ensure Hastelloy C276’s resistance matches the requirements for withstanding chemicals, temperatures, and conditions present.
Coil Thickness and Width: Choose the appropriate thickness and width of coils based on the structural requirements and dimensions of the components or equipment being fabricated.
Surface Finish: Consider the desired surface finish of the coils, whether smooth or textured, based on the intended application and aesthetic preferences.
Mechanical Properties: Assess the mechanical properties such as tensile strength, yield strength, and elongation to confirm that Hastelloy C276 coils meet the structural and performance requirements of the application.
Coil Form: Determine whether flat coils, slit coils, or oscillate wound coils are required based on the specific manufacturing and installation requirements of the application.
No, Hastelloy C276 coils do not rust. They are highly resistant to corrosion, including rust, due to their composition, which includes nickel, chromium, and molybdenum. This alloy provides excellent protection against various corrosive environments, making Hastelloy C276 an ideal choice for applications where corrosion resistance is critical.
