Stainless Steel 317 Forged Fittings stand as indispensable components carefully custom-built from Stainless Steel 317, a variant renowned for its remarkable corrosion resistance and formidable strength, even amidst high-temperature settings. Formulated with a precise blend of iron, chromium, and molybdenum, these fittings epitomize durability and resilience, particularly in environments susceptible to corrosion and elevated temperatures. Offering a comprehensive range from elbows and tees to couplings and unions, Stainless Steel 317 Forged Fittings ensure steadfast performance across a spectrum of demanding applications.
Standard | ASTM A182 / ASME SA182 |
Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
Type | Socketweld Fittings, Screwed-Threaded Fittings |
Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer Stainless Steel 317 Forged Fittings as per DIN, ISO, JIS or ANSI Standard.
Due to their exceptional properties,Stainless Steel 317 Forged Fittings are essential components across many industrial sectors. Renowned for their corrosion resistance, they find widespread application in marine environments, enduring the rigours of saltwater exposure with longevity and reliability. In the construction industry, stainless steel fasteners play a pivotal role in structural assemblies, providing secure connections while maintaining structural integrity in outdoor and exposed settings.
Identify application requirements: Understand your application’s specific requirements, including operating conditions, temperature range, pressure levels, and fluid compatibility. This will help narrow down the options and select fittings with which they seek to work.
Material options: 317 stainless steel provides excellent corrosion resistance and high-temperature performance, making it suitable for various applications. But if your application requires additional features such as greater corrosion resistance or increased mechanical strength, consider another stainless steel grade or alloy.
Fitting Type and Configuration: Specify the fitting type required for your application, such as elbows, tees, couplings, unions, or adapters. Consider fittings’ size, shape and layout to ensure compatibility with existing piping systems and equipment.
Pressure Rating and Standard Compliance: Check the pressure rating and standard compliance of stainless steel 317 forged fittings to ensure they can withstand operating pressures and meet industry standards such as ASME, ASTM, ANSI, and DIN.
Stainless Steel 317 Forged Fittings typically exhibit some degree of magnetism due to their composition, which includes iron. However, the amount of magnetism can vary depending on factors such as the manufacturing process and specific alloy composition.
Yes, Stainless Steel 317 Forged Fittings can be recycled after use. Stainless steel is highly recyclable, and the material retains its properties even after multiple recycling processes. Recycling reduces the need for new raw materials, conserves energy, and minimizes environmental impact, making it a sustainable choice.
Stainless Steel 317 Forged Fittings are generally not recommended for cryogenic applications due to their reduced toughness and potential for embrittlement at low temperatures. Specialized alloys with better cryogenic properties, such as austenitic stainless steels with low carbon content, are preferred for such applications to ensure reliability and safety.
Yes, Stainless Steel 317 Forged Fittings are recyclable after use. Stainless steel is a highly recyclable material, and the fittings can be melted down and reprocessed without losing their properties. Recycling stainless steel reduces the need for new raw materials, making it an environmentally sustainable choice.
